RC0402FR-07100KL: Guide to 100k Ohm Thick Film Resistors

What if the smallest passive component on your bill of materials is quietly eroding your manufacturing margins? Sourcing the standard rc0402fr 07100kl thick film chip resistor through traditional catalog distributors often means absorbing inflated markups and battling 17- to 23-week factory lead times. You already know that keeping your SMT lines running shouldn't require trading cost efficiency for component reliability, especially when dealing with high-volume circuit essentials.

We're here to show you a smarter, leaner procurement path. In this guide, you'll master the critical technical parameters of this 100k Ohm 0402 resistor and discover how to secure direct OEM pricing without tier-1 distributor premiums. We review essential electrical specifications, examine ISO-compliant testing for commercial and automotive grade components, and outline how a strategic logistics pipeline delivers authentic parts to your facility in real time, on time.

Decoding the RC0402FR-07100KL Part Number and Specifications

High-density surface mount assemblies depend on standardized, reliable passive components. The rc0402fr 07100kl represents one of the most widely specified thick film chip resistors in modern electronics, serving as an industry benchmark for pull-up, pull-down, and voltage-divider networks. Decoding its alphanumeric code provides engineers and procurement specialists with critical information regarding its form factor, performance envelope, and packaging standards.

Breakdown of the RC Series Part Numbering System

The part number follows the standardized global numbering convention for thick film passives. Each segment reveals a crucial mechanical or electrical attribute:

• RC: Designates general-purpose thick film chip resistor construction utilizing a metal glaze resistive element on a high-grade ceramic substrate.
• 0402: Indicates the imperial package dimensions of 0.04 inches by 0.02 inches (1.0 mm by 0.5 mm, metric 1005).
• F: Specifies a precision resistance tolerance of ±1.0%.
• R: Identifies standard paper tape packaging on embossed reels.
• 07: Denotes standard 7-inch (178 mm) reel packaging, typically holding 10,000 pieces per reel.
• 100K: Declares the nominal resistance value of 100 kΩ (100,000 Ohms).
• L: Signifies RoHS compliance and lead-free matte tin over nickel barrier terminations.

Key Electrical Parameters of the 100k Ohm 0402

Operating within dense SMT layouts requires strict adherence to power and thermal limits. The 100k Ohm 0402 device delivers robust performance across key operational thresholds:

• Power Rating: Rated at 1/16 W (0.0625 W) at a 70°C derating curve, which fits low-drain digital logic circuits and active analog biasing.
• Voltage Limitations: Supports a maximum continuous working voltage of 50 V, alongside a maximum overload voltage threshold of 100 V and dielectric withstanding voltage of 100 V.
• Temperature Coefficient of Resistance (TCR): Features a TCR of ±100 ppm/°C, preventing resistance drift across fluctuating operational conditions.
• Thermal Range: Operates reliably between -55°C and +155°C, supporting severe industrial operating environments.
